Zabbix 6.4 is here

The new version of Zabbix 6.4 introduces a number of interesting new features.

Contact us for a free consultation CONTACT US FOR A FREE CONSULT AND DEMO
Three new thematic webinars are getting ready for you as we speak CHECK OUT OUR WEBINARS
Training for the latest LTS version (Zabbix 6.0) is now available

MORE INFO ABOUT THE TRAINING

You can also click through our DEMO Zabbix. Sign in by clicking the “sign in as guest” button

SIGN IN TO THE ZABBIX DEMO

New menu layout

The new version introduces an updated menu layout with the following changes:

  • Dashboards got their own separate item
  • There is a new Alerts menu, which brings together everything about alerting, including all types of actions (TriggerActions, ServiceActions, etc.)
  • A new Users menu has also been added, which contains everything about user management, such as User groups, User roles, Users, API tokens and Authentication
  • The latest addition is the new Data collection menu, which replaces the previous Configuration menu and contains subsections related to data collection configuration
Data collection

Zabbix server support for older proxies

In a server-proxy setup, the upgrade procedure has become more flexible. Now, Zabbix server officially supports data collection, execution of remote commands, and immediate item value checks by outdated proxies that are no older than Zabbix server previous LTS release version.

Improved context menus

The context menus for items, hosts and events have been greatly improved.

The host context menu now offers options to switch to a list of items, triggers, discovery rules or web scenarios.

Zabbix server

In the context menu for Item, you can now:

  • view and click-through to triggers linked to the item
  • create a trigger, dependent item or discovery rule linked to the selected item
  • click-through to the Latest data of the selected item
Triggers

And finally, the event context menu now offers the option to:

  • confirm or update the problem
  • view all items used by the problem trigger and go to the configuration of any of them
CPU

Automated account creation from LDAP and SAML

The ability to automatically create users has been a long-awaited and desired feature. Since Zabbix 6.4, it is now possible to manage users and their permissions, including mapping to groups, via AD, LDAP or SAML.

SAML

Easier media type configuration for Gmail and Office365

Gmail or Office365 users can now benefit from easier media type configuration. The new Email provider field in the mail media type configuration allows you to select pre-configured options for Gmail and Office 365 (in addition to the “Generic SMTP” option which works the same as before).

Office365

If you select O365 or Gmail, only an e-mail address and password are now required. Zabbix will automatically fill in all required settings for these media types with the current/recommended values, i.e. SMTP server, SMTP server port, SMTP password and connection security.

Office365

Dynamic background colour for Item Value widget

The Item Value widget now allows you to configure a dynamic background colour based on set thresholds and the last received value.

Item Value widget on Dashboard
Item Value widget configuration

Mandatory old password entry when changing password

When changing password, you will now be required to enter the original password.

SNMP optimization

The part of the SNMP using BULK request has been redesigned. Now Zabbix accesses multiple metrics in the same way as a standard bulk request. This change solves, for example, problems when using proxy and SNMP Discovery, when Zabbix was not able to report all data or when Zabbix displayed the message: “SNMP error: noCreation (That table does not support row creation or that object can not ever be created)”.

New snmp.walk item

Since Zabbix 6.4, there has been a new snmp.walk[] item which returns a multi-line list of values.

For example, snmp.walk[1.3.6.1.2.1.2.2.1.2,1.3.6.1.2.1.2.2.1.3] will return:

.1.3.6.1.2.1.2.2.1.2.1 = STRING: "lo"
.1.3.6.1.2.1.2.2.1.2.2 = STRING: "ens33"
.1.3.6.1.2.1.2.2.1.2.3 = STRING: "ens37"
.1.3.6.1.2.1.2.2.1.3.1 = INTEGER: 24
.1.3.6.1.2.1.2.2.1.3.2 = INTEGER: 6
.1.3.6.1.2.1.2.2.1.3.3 = INTEGER: 6

New preprocessing options

In connection with the changes in SNMP, two new, very useful preprocessing options have been added:

  • SNMP walk value – Selects a value by the specified OID/MIB name and applies the selected formatting to it.
  • SNMP walk to JSON – Converts SNMP to JSON format.

Cause and symptoms of problems

In Zabbix version 6.4 has been added the possibility to mark the generated events as a secondary symptom of a larger problem. For example, when a network switch fails, Zabbix notifies only a problem with the switch itself and everything else which is dependent on this device is only a symptom, not the main problem. Just select all the emerged issues and click on the name of the event you want to mark as the main one.

Ack has been renamed to “update”

The “Ack” link in the issue list has been renamed to “Update”, so that the name of the link better reflects all of the recently available options for issue updating.

Template versioning

Templates now display their version and creator. This is the next step to versioning templates directly in Zabbix. For now, it is only about visualization and not versioning itself, but we already have an idea of how to use this functionality for the Zabbix module with a connection to git.

Metrics and Events streaming now supports external systems via HTTP

It will now be possible to forward metrics to other systems in real time. In particular, collected metrics and generated events can now be sent. There’s now a possibility to filter with tags as well as the option to log in to the target using either combination of a username and password or a certificate. You can also choose the number of parallel connections and the option to send messages in batches or one by one. The HTTP request is made using the POST method.

Example of the HTTP request:

POST / HTTP/1.1
Host: log-management.initmax.cz
Accept: */*
Accept-Encoding: deflate, gzip, br
Content-Type: application/x-ndjson
Content-Length: 4869{"host":{"host":"demo.initmax.cz","name":"demo.initmax.cz"},"groups":["Zabbix","Connector","DEMO"],"item_tags":[{"tag":"Target","value":"OpenSearch"},{"tag":"Target","value":"WAZUH"}],"itemid":147414,"name":"Demo item value, % free","clock":1675972194,"ns":97908485,"value":99.745535424749832,"type":0}

Configuration import

A new option to “import all” has been added to the template/guest configuration form. When all is checked, then all importable items will be selected.

To see the list of options in the import rules, the “Advanced options” checkbox must now be selected.

Another change is that the option to “Remove Missing” is now checked by default.

New widget framework and documentation for developers

In the Zabbix documentation, you will now find a section with instructions for using the new widget framework with a working example on the new alarm clock widget.

The widget can be seen on our DEMO zabbix.

You can find the Demo Zabbix here: https://www.initmax.com/zabbix/

Framework documentation: https://www.zabbix.com/documentation/devel/en/devel

New templates

  • AWS RDS instance by HTTP
  • AWS S3 bucket by HTTP
  • Azure by HTTP
  • OPNsense by SNMP
  • Cisco Meraki dashboard by HTTP
  • Veeam Backup and Replication by HTTP
  • Veeam Backup Enterprise Manager by HTTP

As official partners and big fans of the Zabbix platform, we can provide you with the highest level of service in all areas of Zabbix monitoring. If you are interested in a live demonstration of Zabbix installations at our customers, we will be happy to show you Zabbix in practice.
